Product Details:
|
| Features: | Easy -installing | Application: | RF Signal |
|---|---|---|---|
| Type: | Wholesale & Engineering | Series: | Amplifier |
| Mounting Type: | Self Installing | Description: | High Efficiency |
| Manufacturing Date Code: | 202301xx | Frequency Range: | 430-434MHz |
| Voltage: | 12-20v | Gain(S21): | 17db±1 |
| Max Output Power(P1dB): | 40dBm(10w) | EVM: | 3%@37dBm 802.11g 54Mbps OFDM 64QAM BW 20MHz |
| Current Supply: | 1.2A@Pout 37dBm 12V | TX/RX Switch Time Delay: | <1 Us |
| RF Connector: | Input: SMA-female; Output: SMA-female | Port: | Shenzhen/Shanghai |
| Highlight: | 434MHz RF Amplifier Module,RF Amplifier Module 40dBm,40dBm rf power module |
||
Boost Your Lora Interphone: 430-434MHz Amplifier Module With 40dBm Output
1.Descriptions
Boost Your Lora Interphone: 430-434MHz Amplifier Module With 40dBm Output
This Lora walkie-talkie signal amplifier module in the 430-434MHz frequency band has an output power of up to 40dBm, which can significantly improve the signal coverage and communication stability of the Lora walkie-talkie. It is specially designed for Lora devices that require long-distance, low-power communication, and is especially suitable for use in scenarios that require reliable, long-distance communication, such as industrial control, agricultural monitoring, and smart cities. By increasing signal strength, the amplifier module ensures stable communication transmission in environments with interference or weak signals.
2.Product Specifications
| No. | Items | Specifications |
| 1 | Frequency range | 430MHz-434Mhz |
| 2 | Operating Voltage | 8-18V |
| 3 | Gain(S21) | 37db |
| 4 | Output Power | 17dB卤1 |
| 5 | Max Output Power(P1dB) | 40dbm(10w) |
| 6 | RF Connector | Input: SMA-female; Output: SMA-female |
| 7 | Net Weight | 0.35Kg |
3.Product Advantages
4.Product details
What includes if you order this?
Contact Person: Mr. tommy
Tel: 18625215257
