Product Details:
|
| Features: | High | Application: | Signal Allocation |
|---|---|---|---|
| Type: | Signal Allocation Device | Series: | Wifi Parts |
| Mounting Type: | Turnkey Solution | Description: | Low Insertion Loss |
| Manufacturing Date Code: | 202304XX | Frequency Range: | 600-6000MHz |
| VSWR: | ≤1.2 | Directivity: | 20dB |
| Insertion Loss: | ≤0.3dB | Coupling Value: | 10dB |
| Coupling Tolerance: | ± 1dB | Input Power: | ≤43 DBm |
| Impedance: | 50 Ohms | Port Connection: | N-Female |
| Net Weight: | 0.2Kg | Port: | Shenzhen/Shanghai |
| Highlight: | 10dB Dual Directional Coupler,Dual Directional Coupler Dual Directional Coupler,10dB bi directional coupler |
||
Efficient 10dB Coupling Dual Directional Coupler Low Insertion Loss For 2G-5G
1.Descriptions
Efficient 10dB Coupling Dual Directional Coupler Low Insertion Loss For 2G-5G
This highly efficient 10dB coupled bidirectional coupler is designed for 2G to 5G signals and features low insertion loss. Its optimized performance ensures efficient and stable signal transmission and is suitable for a variety of wireless communication applications such as base stations and test equipment.
2.Product Specifications
| No. | Items | Specifications |
| 1 | Frequency range | 600-6000MHz |
| 2 | Band | 698-960MHz,1710-2700MHz,3300-3700MHz, 4900-5850MHz |
| 3 | VSWR | ≤1.2 |
| 4 | Directivity | 20dB |
| 5 | Insertion Loss | ≤0.3dB |
| 6 | Coupling Value | 10dB |
| 7 | Coupling Tolerance | ±1dB |
| 8 | Input Power | 43 dBm |
| 9 | Port Connectors | N-Female |
| 10 | Size | 112*20*20(mm |
| 11 | Net Weight | 0.20Kg |
3.Product Advantages
4.Product details
ACASOM IOT 600-6000MHz Microstrip
Line Directional Coupler
Working Band: 600-6000MHz
The IOT Wideband 10dB Directional coupler is rated for a minimum frequency of 600MHz and a maximum frequency of 6000MHz. The Wideband 10dB Directional Coupler has 0.3dB insertion loss, and 1.2 VSWR.The Wideband 10dB Directional Coupler features rugged aluminum construction and is used indoor.The Wideband 10dB Directional Coupler has a female type N input, a female type N output and a female type N couple port.
